GWN7615

GWN 802.11ac Wave-2 3x3:3 Access Point
The GWN7615 is an enterprise performance 802.11ac Wave-2 Wi-Fi access point to create scalability for medium to high user density environments. It offers dual-band 3×3:3 MU-MIMO technology and a sophisticated antenna design for maximum network throughput and expanded Wi-Fi coverage range.

  • 1.75Gbps aggregate wireless throughput and 2x Gigabit wireline ports
  • Dual-band 3x3:3 MU-MIMO technology
  • Self power adaptation upon auto detection of PoE or PoE+
  • Support 200+ concurrent Wi-Fi client devices
  • Up to 175-meter coverage range
  • Advanced QoS to ensure real-time performance of low-latency applications
  • Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
  • Embedded controller can manage up to 50 local GWN series APs; GWN.Cloud offers unlimited AP management; GWN Manager offers premise based software controller

Free Network Management Options

www.grandstream.comhubfsgwn cloud combinationn graphic

GWN.Cloud

GWN.Cloud is a enterprise-grade, management platform for Grandstream networking products. Secure networks can be deployed in seconds using GWN.Cloud mobile app or the web browser interface, then later managed from the same interface. Keep an eye on the network’s performance with real-time monitoring, alerts, statistics and reports that can be viewed using a web browser or the mobile application, then later managed from either interface.

GDMS Networking
gwnmanager_thumbnail

GWN Manager

GWN Manager is a  on-premise enterprise- grade, management platform for an unlimited number of Grandstream networking products. Typically deployed on a customer’s private network, this solution offers simplified configuration and management. Keep an eye on the network’s performance with real-time monitoring, alerts, statistics and reports that can be viewed using a web browser or the mobile application.

GWN Manager
embedded_controller_thumbnail

Embedded Controller

Grandstream's GWN networking products include an embedded controller software at no extra cost and it is simply built-in to the product’s web user interface. Our embedded controllers can auto discovery and auto-provision any in-network GWN series networking product which also offers a centralized provisioning and management interface.





Product Highlights


Affordable Advanced Features

The GWN7615 is a competitive Wi-Fi device that was designed for a low price point with high performance, perfect for more cost-sensitive and mid-volume Wi-Fi deployments like cafes, lecture halls, and offices.

  • Market Leading Wi-Fi Standards: Wave-2 IEEE 802.11a/b/g/n/ac standards, this supports past, present, and future Wi-Fi devices
  • Greater Performance for Less Money: 200+ concurrent devices, 165-meter coverage range, 1.27Gbps aggregate
  • Beamforming Technology: AP detects wireless clients and focuses signals on them
  • QoS Standards: Prioritizes certain network traffic/devices so critical tasks don't compete for bandwidth, can be customized based on deployment

Basic Deployment Concepts GWN Access Points

In this video, we go over some high-level explanations of what is involved in planning, deploying, and optimizing GWN7600 series access points. The information in this video will help installers design a wireless network that will provide the required Wi-Fi coverage, data rates, wireless capacity, and roaming capability. These are the points covered in this video:

  • Predictive site survey
  • AP selection
  • Local and cloud management of GWN access points
  • Post-deployment survey
  • Wi-Fi features: RRM, Voice Enterprise, Airtime Fairness, Client Isolation, Band Steering

Self-Guided Networking Solution Training

Grandstream Networks self-training is an effective pre-recorded video training that offers huge flexibility and provides all the information and explanations needed to acquire the necessary knowledge about Grandstream's solutions before taking the certification exam.

This course covers Grandstream's Networking Solution GCS level (Grandstream Certified Specialist). The course is divided into 4 chapters and it has been recorded for you to make sure that you understand the technical specifications, features, and services of our GWN series.

Networking Solution Self-Training (GCS)

Product Comparison


NameGWN7615
Specs
Client Devices 200+
2.4G Throughput 450Mbps (3x3:3 MIMO)
5G Throughput 1300Mbps (3x3:3 MU-MIMO)
6G THROUGHPUT N/A
Range Up to 175 Meters
Network Interfaces 2x autosensing 10/100/1000 Base-T Ethernet Ports
PoE/PoE+ Supports PoE 802.3af/802.3at; Max consumption: 12.5W
Wi-Fi Standards IEEE 802.11a/b/g/n/ac (Wave-2)
SSIDs 32 SSIDs total, 16 per radio (2.4Ghz and 5Ghz)
Antennas 3 dual band internal antennas
Wi-Fi and Security Systems WEP, WPA/WPA2-PSK, WPA/ WPA2 Enteprise, WPA3, anti- hacking secure boot and critical data/control lockdown via digital signatures
Dimensions 205.4x205.4x45.9mm
Mounting Indoor wall mount or ceiling mount
