    GWN7830 / GWN7831 / GWN7832

    Layer 3 Aggregation Network Switches
    The GWN7830 series are Layer 3 aggregation switches that allow enterprises to build scalable, secure, high-performance, and smart business networks that are fully manageable and support maximum capacity.

    • 2/4 Gigabit Ethernet ports, 6/24 Gigabit SFP ports, and  4/12 10Gigabit SFP+ ports
    • Supports deployment in IPv6 and IPv4 networks
    • ARP Inspection, IP Source Guard, DoS protection, port security & DHCP snooping
    • Embedded controller to manage switch; GDMS Networking and GWN Manager, Grandstream’s cloud and on-premise network management platform
    • Built-in QoS allows for prioritization of network traffic
    Contact Sales
    Product Resources & Documentation
    ...
    ...
    ...
    ...
    ...
    ...
    ...
    ...
    ...
    ...
    ...
    ...
    ...
    ...



    Layer 3 Aggregation Switches

    The GWN7830 Series are layer 3 aggregation switches that provide 4 or 12 SFP+ ports, 6 or 24 SFP ports, and 2 or 4 Gigabit Ethernet ports.





    High-Performance Networking

    The GWN7830 Series includes SFP+ optical ports on all models, up to 12 ports, for up to 240Gbps switching capacity.





    Maximum Network Control and Management

    Advanced VLAN, a state-of-the-art QoS, IGMP/MLD Snooping, flexible security settings, and extensive reliability protection
    provide network admins with full network control.





    Built-In Surge Protection

    4KV and 6KV surge protection safeguards your network and equipment against abnormal power events and provides reliability.





    Power Redundancy

     A dual power supply design allows the GWN7831 and GWN7832 to offer redundancy and ensure uninterrupted operation
    in case of isolated power failure scenarios.





    Free, Centralized Cloud Management

    Deploy and manage the GWN7830 Series, and all Grandstream solutions, centrally from the cloud using the
    free Grandstream Device Management System (GDMS).





    Supports Stacking

    Coming Soon - Easily manage multiple switches using one interface while creating redundant backup between multiple devices.



    Free Network Management Options

    gdms-networking-thumbnail

    GDMS Networking

    GDMS Networking is an enterprise-grade, cloud management platform for Grandstream networking products.

    GDMS Networking
    gwn-manager-thumbnail-2

    GWN Manager

    GWN Manager is an on-premise enterprise- grade, management platform for an unlimited number of Grandstream networking products.

    GWN Manager
    embedded_controller_thumbnail

    Embedded Controller

    Grandstream's GWN networking products include an embedded controller software and is built-in to the product’s web user interface.






    Product Highlights

    High Performance with Maximum Network Capacity and Control for Enterprises and Medium-to-Large Businesses

    Grandstream's GWN7830 Series network switches are ideal for enterprises and medium-to-large businesses that require high-performance networks with maximum network capacity and control.

    • Supports advanced VLAN for flexible and sophisticated traffic segmentation, advanced QoS for prioritization of network traffic, IGMP/MLD Snooping for network performance optimization, and comprehensive security capabilities against potential attacks.
    • The GWN7830 series can be managed in several ways, including the local Web user interface of the switch, and CLI, the command line interface. This series is also supported by GWN.Cloud and GWN Manager, Grandstream’s cloud and on-premise network management platform.
    • The GWN7830 Series provides enterprise-grade Layer 3 aggregation switches ideal for medium-to-large deployments

    Product Comparison

    NameGWN7830
    Specs
    Network Protocols IPv4, IPv6, IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3AB, IEEE 802.1p, IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x
    Gigabit Ethernet Ports 2
    SFP Ports 6
    SFP+ 10Gigabit Ports 4
    Total Non-Blocking Throughput 48Gbps
    Switching Capability 96Gbps
    Forwarding Rate 71.424Mpps
    QoS
    • Port priority
    • Priority mapping
    • Queue scheduling, including SP, WRR, WFQ, SP-WRR, and SP-WFQ
    • Traffic shaping
    • Rate limit
    Switching, Routing, and Multicast
    • 16K static, dynamic, and filtering MAC addresses
    • 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, voice VLAN
    • 6 Link Aggregation
    • 2K ACL for Ethernet, IPv4, and IPv6
    • VLAN virtual interface
    • GVRP (pending)
    • Spanning tree, 32 instances for STP/RSTP/MSTP
    • Static routing
    • Dynamic routing, including RIP, RIPng, OSPF and OSPFv3
    • Policy routing (pending)
    • IGMP Snooping
    • MLD Snooping
    • MVR (pending)
    Security
    • User hierarchical management and password protection, HTTPS, SSH, Telnet
    • 802.1X authentication
    • AAA authentication including RADIUS, TACACS+
    • Storm control
    • Port isolation, port security, sticky MAC
    • Filtering MAC address
    • IP source guard, DoS attack prevention, ARP inspection
    • DHCP Snooping
    • Loop protection including BPDU protection, root protection(pending) and loopback protection(pending)
    • Kensington Security Slot (Kensington Lock) support
