GWN7664

GWN 4x4:4 Wi-Fi 6 Indoor Access Point
The GWN7664 is a powerful, enterprise-grade 802.11ax Wi-Fi 6 access point, ideal for medium-to-large sized businesses, multiple floor buildings, residential settings and commercial locations.

  • 3.55Gbps aggregate wireless throughput, 3.5Gbps aggregate wired throughput
  • Dual-band 4x4:4 MU-MIMO with DL/UL OFDMA technology
  • Up to 175-meter coverage range
  • Supports 750+ concurrent Wi-Fi client devices
  • Includes 1x 1G Port and 1x 2.5G Port
  • Advanced QoS to ensure real-time performance of low-latency applications
  • Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
  • Self power adaptation upon auto detection of PoE or PoE+
  • Embedded controller manages up to 50 local GWN APs; GWN.Cloud offers unlimited AP management, & GWN Manager offers on-premise software AP management

Free Network Management Options

www.grandstream.comhubfsgwn cloud combinationn graphic

GWN.Cloud

GWN.Cloud is a enterprise-grade, management platform for Grandstream networking products. Secure networks can be deployed in seconds using GWN.Cloud mobile app or the web browser interface, then later managed from the same interface. Keep an eye on the network’s performance with real-time monitoring, alerts, statistics and reports that can be viewed using a web browser or the mobile application, then later managed from either interface.

GWN.Cloud
gwnmanager_thumbnail

GWN Manager

GWN Manager is a  on-premise enterprise- grade, management platform for an unlimited number of Grandstream networking products. Typically deployed on a customer’s private network, this solution offers simplified configuration and management. Keep an eye on the network’s performance with real-time monitoring, alerts, statistics and reports that can be viewed using a web browser or the mobile application.

GWN Manager
embedded_controller_thumbnail

Embedded Controller

Grandstream's GWN networking products include an embedded controller software at no extra cost and it is simply built-in to the product’s web user interface. Our embedded controllers can auto discovery and auto-provision any in-network GWN series networking product which also offers a centralized provisioning and management interface.





Product Highlights


Amritapuri University Wi-Fi and UC Solution

Considering the large size of the Amritapuri campus, a Wi-Fi connection was needed to be deployed throughout dorm rooms, staff rooms, classrooms, outer areas, and more. There was also a need to implement 802.1X radius-based authentication for all faculties, students, researchers, etc. with dynamic support.

The GWN7664 was installed all over the Amritapuri Campus as this powerful indoor Wi-Fi 6 Access Point is ideal for multiple-floor buildings and commercial locations. A total of 65 GWN7664 products were deployed to provide the latest Wi-Fi 6 technology with OFMDA/MU-MIMO and ensure coverage throughout the 1200-acre campus.

Read Case Study

Introduction Webinar to the GWN7664

This webinar recording provides an introductory overview of our new GWN Wi-Fi access point, the GWN7664. This Wi-Fi 6 access point is our strongest yet, providing dual-band 4x4:4 MU-MIMO and 3.55Gbps aggregate wireless throughput!

Watch the webinar and learn about the technical details, key capabilities, and deployment scenarios of the GWN7664 Wi-Fi 6 access point.

Watch Now

Wi-Fi 6

Wi-Fi Alliance® is the worldwide network of companies bringing you Wi-Fi®, one of the world’s most valued communications technologies. Our vision is to connect everyone and everything, everywhere. Wi-Fi Alliance drives global Wi-Fi adoption and evolution through thought leadership, spectrum advocacy, and industry-wide collaboration. Grandstream’s Wi-Fi 6 access points have been CERTIFIED, meaning they have undergone rigorous testing. When a product passes the tests successfully, the manufacturer can use the Wi-Fi CERTIFIED logo.

Certification means that a product has been tested in numerous configurations with a diverse sample of other devices to validate interoperability with other CERTIFIED Wi-Fi equipment operating in the same frequency band.

Market-Leading Features

The GWN7664 comes equipped with advanced performance-boosting features:
  • UL/DL OFDMA: Access points running on the 801.11ax standard perform better in dense environments and are designed to manager multiple Wi-Fi devices with varying bandwidth demands
  • Beamforming Technology: AP detects wireless clients and focus signals towards them
  • Multiple Customized SSIDs: Up to 32 SSID channels with customized client configurations, captive portal, and bandwidth limits
  • QoS Standards: Prioritizes certain network traffic/devices so critical tasks don't compete for bandwidth, can be customized based on deployment

Product Comparison


NameGWN7664
Specs
Client Devices Up to 750
Range Up to 175 Meters
Network Interfaces 1x 1G Port and 1 x 2.5G Port
PoE/PoE+ Supports PoE 802.3af/802.3at; Max Consumption: 17w
2.4G Throughput 1147Mbps (4x4:4 MIMO)
5G Throughput 2400Mbps (4x4:4 MU-MIMO)
6G THROUGHPUT -
Wi-Fi Standards IEEE 802.11 a/b/g/n/ac/ax
SSIDs 32 SSIDs total, 16 per radio (2.4 Ghz and 5Ghz)
Antennas 8 individual internal antennas, 4 per band
Wi-Fi and Security Systems WEP, WPA/WPA2-PSK, WPA/ WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device
Dimensions 205.3x205.3x405.9mm
Mounting Indoor wall mount or ceiling mount, kits included

Related Products



  • 1.77Gbps aggregate wireless throughput and 2x Gigabit Ethernet ports
  • Dual-band 2x2:2 MUMIMO with DL/UL OFDMA technology
  • Up to 175-meter coverage range
  • Supports 256 concurrent Wi-Fi client devices
  • Advanced QoS to ensure real-time performance of low-latency applications
  • Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
  • Self-power adaptation upon auto detection of PoE or PoE+
  • Embedded controller can manage up to 50 local GWN series APs; GWN.Cloud offers unlimited AP management; GWN Manager offers premise based software controller

  • 5.38 Gbps wireless throughput and 3.5 Gigabit wireline ports
  • 5GHz 4×4:4 MU-MIMO with DL/UL OFDMA technology
  • Up to 175-meter coverage range
  • Supports 256 concurrent Wi-Fi client devices
  • Advanced QoS to ensure real-time performance of low-latency applications
  • Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
  • Self power adaptation upon auto detection of PoE or PoE+
  • Embedded controller can manage up to 50 local GWN series APs; GWN.Cloud offers unlimited AP management; GWN Manager offers premise based software controller

  • 3.55Gbps aggregate wireless throughput, 3.5Gbps aggregate wired throughout
  • Dual-band 4x4:4 MU- MIMO with DL/UL OFDMA technology
  • Self power adaptation upon auto detection of PoE or PoE+
  • Support 750+ concurrent Wi-Fi client devices
  • Up to 300-meter coverage range
  • Advanced QoS to ensure real-time performance of low-latency applications
  • Anti-hacking secure boot and critical data/control lockdown
  • Flexibility of 4 detachable/changeable antennas for different application scenarios
  • Embedded controller manages up to 50 local GWN APs; GWN.Cloud offers unlimited AP management, & GWN Manager offers on-premise software AP management

  • 1.77Gbps aggregate wireless throughput and2x Gigabit Ethernet ports
  • Dual-band 2×2:2 MU- MIMO with DL/UL OFDMA technology
  • Self power adaptation upon auto detection of PoE or PoE+
  • Support 256+ concurrent Wi-Fi client devices
  • Up to 250-meter coverage range
  • Advanced QoS to ensure real-time performance of low-latency applications
  • Anti-hacking secure boot and critical data/control lockdown
  • Flexibility of 2 detachable/changeable antennas for different application scenarios
  • Embedded controller manages up to 50 local GWN APs; GWN.Cloud offers unlimited AP management, & GWN Manager offers on-premise software AP management
