GWN7662
GWN 2x2:2 & 4x4:4 Wi-Fi 6 Indoor Access Point
The GWN7662 is an enterprise-grade 802.11ax Wi-Fi 6 access point that allows businesses to build next generation Wi-Fi networks for high-density environments.
- 5.38 Gbps wireless throughput and 3.5 Gigabit wireline ports
- 5GHz 4×4:4 MU-MIMO with DL/UL OFDMA technology
- Up to 175-meter coverage range
- Supports 256 concurrent Wi-Fi client devices
- Advanced QoS to ensure real-time performance of low-latency applications
- Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
- Self power adaptation upon auto detection of PoE or PoE+
- Embedded controller can manage up to 50 local GWN series APs; GWN.Cloud offers unlimited AP management; GWN Manager offers premise based software controller










Free Network Management Options

GWN.Cloud
GWN.Cloud is a enterprise-grade, management platform for Grandstream networking products. Secure networks can be deployed in seconds using GWN.Cloud mobile app or the web browser interface, then later managed from the same interface. Keep an eye on the network’s performance with real-time monitoring, alerts, statistics and reports that can be viewed using a web browser or the mobile application, then later managed from either interface.

GWN Manager
GWN Manager is a on-premise enterprise- grade, management platform for an unlimited number of Grandstream networking products. Typically deployed on a customer’s private network, this solution offers simplified configuration and management. Keep an eye on the network’s performance with real-time monitoring, alerts, statistics and reports that can be viewed using a web browser or the mobile application.

Embedded Controller
Grandstream's GWN networking products include an embedded controller software at no extra cost and it is simply built-in to the product’s web user interface. Our embedded controllers can auto discovery and auto-provision any in-network GWN series networking product which also offers a centralized provisioning and management interface.
Product Highlights
Wi-Fi 6
Wi-Fi Alliance® is the worldwide network of companies bringing you Wi-Fi®, one of the world’s most valued communications technologies. Our vision is to connect everyone and everything, everywhere. Wi-Fi Alliance drives global Wi-Fi adoption and evolution through thought leadership, spectrum advocacy, and industry-wide collaboration. Grandstream’s Wi-Fi 6 access points have been CERTIFIED, meaning they have undergone rigorous testing. When a product passes the tests successfully, the manufacturer can use the Wi-Fi CERTIFIED logo.
Certification means that a product has been tested in numerous configurations with a diverse sample of other devices to validate interoperability with other CERTIFIED Wi-Fi equipment operating in the same frequency band.
Wi-Fi Communications Guide
As business requires more mobility and flexibility, organizations are relying on Wi-Fi networks not only for data and internet but also for their communications and collaboration platform. With over 100 products in our offering, including a full portfolio of Wi-Fi networking solutions as well as a deep portfolio of voice and video solutions, Grandstream provides a one-stop shop for all of your Wi-Fi and unified communication needs.
Click below to read our Wi-Fi Communications Solutions Guide and learn about:
- Why your Wi-Fi networks should also support voice & video solutions
- How to optimize a Wi-Fi solution for voice and video communication
- Using a Wi-Fi voice/video solution to control facility access

Market-Leading Features
The GWN7664 comes equipped with advanced performance-boosting features:- UL/DL OFDMA: Access points running on the 801.11ax standard perform better in dense environments and are designed to manage multiple Wi-Fi devices with varying bandwidth demands
- Beamforming Technology: AP detects wireless clients and focuses signals towards them
- Multiple Customized SSIDs: Up to 32 SSID channels with customized client configurations, captive portal, and bandwidth limits
- QoS Standards: Prioritizes certain network traffic/devices so critical tasks don't compete for bandwidth, can be customized based on deployment

Product Comparison
NameGWN7662 |
---|
![]() |
Specs |
Client Devices Up to 256 |
Range Up to 175 Meters |
Network Interfaces 1x autosensing 10/100/1000 Base-T Ethernet Port, 1x autosensing 10/100/1000/2500 Base-T Ethernet Port |
PoE/PoE+ Supports 802.3az; PoE 802.3af/ 802.3at; Maximum Power Consumption: 16W |
2.4G Throughput 573.5Mbps (2x2:2 MIMO) |
5G Throughput 4804Mbps (4x4:4 MU-MIMO) |
Wi-Fi Standards IEEE 802.11 a/b/g/n/ac(Wave-2)/ax |
SSIDs 32 SSIDs total, 16 per radio (2.4GHz & 5GHz) |
Antennas 6 single frequency internal antennas |
Wi-Fi and Security Systems WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/ control lockdown via digital signatures |
Dimensions 205.3mmx205.3mmx45.9mm |
Mounting Indoor wall mount or ceiling mount |
