    GWN7674

    High-Performance Tri-Band Wi-Fi 7 Access Point
    The GWN7674 is a powerful enterprise-grade Wi-Fi 7 access point that provides wireless speeds up to 21Gbps (BE21000), ideal for medium-sized businesses and large enterprises with medium to high user density.

    • 21Gbps aggregate wireless throughput, 12.5Gbps aggregate wired throughput
    • Integrated Wi-Fi 7 & 4x4:4 MU-MIMO on 5G and 6G band and 2x2:2 MU-MIMO on 2.4G band with MLO, 4KQAM, MRU, Premable Puncturing Technology
    • Up to 175-meter coverage range
    • Supports 768 concurrent Wi-Fi client devices
    • Advanced QoS to ensure real-time performance of low-latency applications
    • Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
    • Self-power adaptation upon auto-detection of PoE++
    • Embedded controller manages up to 50 local GWN APs; GDMS Networking offers unlimited AP management, & GWN Manager offers on-premise software AP management
    Contact Sales
    Product Resources & Documentation
    ...
    ...
    ...
    ...
    ...
    ...
    ...
    ...
    ...
    ...
    ...
    ...
    ...
    ...
    ...
    ...



    State-of-the-Art Wi-Fi 7 Connectivity

    The GWN7674 is built on Wi-Fi 7, which provides faster speeds, lower latency, and increased capacity compared to previous Wi-Fi standards.



    Tri-Band Maximizes Speeds and Clients

    The GWN7674 provides three bands to fully utilize spectrum resources while maximizing device support and speeds.



    Ideal for Demanding Environments

    The GWN7674 provides speeds up to 21Gbps while supporting up to 768 clients per AP, making it an ideal solution for high-usage environments.



    High-Performance, Maximum Efficiency

    Devices can connect on multiple bands to ensure that high-priority data gets transmitted without delay while providing faster speeds through aggregation.



    Twice as Fast as Wi-Fi 6

    Wi-Fi 7 channels are twice the size of Wi-Fi 6 channels, allowing Grandstream’s Wi-Fi 7 APs to provide maximum speeds and capacity.



    Easy and Free Management

    Manage Grandstream Wi-Fi APs for free from the cloud (GDMS), software (GWN Manager), app (GDMS app), and the AP itself using its built-in controller.

    Free Network Management Options

    gdms-networking-thumbnail

    GDMS Networking

    GDMS Networking is an enterprise-grade, cloud management platform for Grandstream networking products.

    GDMS Networking
    gwn-manager-thumbnail-2

    GWN Manager

    GWN Manager is an on-premise enterprise- grade, management platform for an unlimited number of Grandstream networking products.

    GWN Manager
    embedded_controller_thumbnail

    Embedded Controller

    Grandstream's GWN networking products include an embedded controller software and is built-in to the product’s web user interface.






    Product Highlights

    GWN7674 Key Deployment Scenarios

    The GWN7674 can be deployed in various scenarios including:
    • Offices: Medium and large offices can utilize the GWN Series to create a mobile working environment for employees that doesn't sacrifice on performance.
    • Commerical Shops: Commercial stores can use the GWN Series to create Wi-Fi environments for both guests and staff.
    • Education: Within demanding education environments, the GWN Series can help both staff and students exceed with a rapid wireless connection.

    Wi-Fi 7

    Wi-Fi CERTIFIED 7™ is here to meet the growing user demands for immersive, interactive technology. Based on IEEE 802.11be technology, Wi-Fi CERTIFIED 7 enhances Wi-Fi performance in the 2.4 GHz and 5 GHz bands bringing cutting-edge capabilities to enable innovations that require high throughput, lower latency, and greater reliability across home, enterprise, and industrial environments.

    Wi-Fi CERTIFIED 7 networks support advanced Wi-Fi performance for high bandwidth applications to ensure each connected device delivers the dependable experience users expect, even in dense environments like stadiums and large campuses.

    Product Comparison

    NameGWN7674
    Specs
    Client Devices 768
    2.4G Throughput 688Mbps (2x2:2 MU-MIMO)
    5G Throughput 8647Mbps (4x4:4 MU-MIMO)
    6G Throughput 11529Mbps (4x4:4 MU-MIMO)
    Range Up to 175 Meters
    Network Interfaces 1x 10G Ethernet WAN/LAN, 1x 2.5G Ethernet WAN/LAN
    PoE/PoE+ Supports PoE 802bt; Maximum Power Consumption: 36W
    Wi-Fi Standards IEEE 802.11 a/b/g/n/ac/ax/be
    SSIDs 48 SSIDs total, 16 per radio (2.4GHz, 5GHz, and 6GHz)
    Antennas 12 single built-in antennas
    Wi-Fi and Security Systems Open system, OSEN, WPA2-PSK (personal), WPA2-802.1x (enterprise), WPA3-SAE (personal), WPA3-802.1x (enterprise), WPA/WPA2, WPA2/WPA3, Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device, MAC filtering, Client isolation, OS filtering, Inbound/outbound traffic rules, Rogue AP detection and containment, ARP attack defense, ND attack defense
    Dimensions 250mmx250mmx54.5mm
    Mounting Indoor wall mount or ceiling mount, kits included
